| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC/DC |
| Max. system power | 4.8 W |
| Max. inrush current | 4.50 A |
| Inrush time | 130.00 |
| Displacement factor (DF) | ≥ 0.9 |
| Nominal voltage DC | 180|280 V |
| Frequency | 50|60 Hz |
| Colour temperature | 3000 K |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 400 lm |
| Luminaire efficacy | 83 lm/W |
| Equivalent to | Halogen 35W |
| Colour consistency (SDCM) | 4.0 |
| Colour rendering index (CRI) | > 90 |
| CIE Flux Code | 88 99 100 100 100 |
| Beam angle | 55° |
|---|
| Lifetime (L70) | 50000 h |
|---|---|
| Lifetime (L80) | 30000 h |
| On-/Off-cycles | 100000 |
| Dimmability | On-Off |
|---|
| Protection class | II |
|---|---|
| Degree of protection (IP) | IP20 |
| Impact strength | IK02 |
| Glow wire test | 650°C |
| Risk group (EN 62471) | RG1 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 1.0% |
| Input current | 0.0400 A |
| Housing colour | White |
|---|---|
| Reflector | High-gloss |
| Optical material | Polycarbonate |
| Finishing | Matte White |
| Maximum tilt angle | 90° |
| Length | 55 mm |
|---|---|
| Width | 55 mm |
| Height/depth | 114 mm |
| Outer diameter | 55 mm |
| Application temperature | 25°C |
|---|---|
| Storage environment | -25|50°C |
| Operating temperature | -10|40°C |
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 06941497787132 | 94051190 | CT | 1 | 0.061 x 0.061 x 0.12 m | 0.26 KG |
