Floodlight EcoMax G3
LEDFlood-E3 Re246-70W-840-BL-AS
Product Code
709000117500
- Complete floodlight family from 10 to 200W
- Equipped with breather to prevent condensation
Specifications
Electrical data
| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC |
| Max. system power | 70 W |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 6 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 11 |
| Power factor | 0.9 |
| Surge protection | 4 kV |
| Max. inrush current | 42.6 A |
| Inrush time | 400 |
| Displacement factor (DF) | ≥ 0.9 |
| Max. number of luminaires per miniature circuit breaker C10 (MCB) | 6 |
| Max. number of luminaires per miniature circuit breaker C13 (MCB) | 8 |
| Frequency | 50|60 Hz |
Photometrical data
| Colour temperature | 4000 K |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 10500 lm |
| Luminaire efficacy | 150 lm/W |
| Equivalent to | HID 150W |
| Colour consistency (SDCM) | 4 |
| Colour rendering index (CRI) | > 80 |
| CIE Flux Code | 53 91 99 100 100 |
Light technical data
| Beam angle | 75° x 100° |
|---|
Lifespan
| Lifetime (L70) | 50000 h |
|---|---|
| Lifetime (L80) | 30000 h |
| On-/Off-cycles | 100000 |
Capabilities
| Dimmability | On-Off |
|---|---|
| With sensor | F |
| Sensor technology | No sensor |
| Sensor type | No sensor |
Certificates and standards
| Protection class | I |
|---|---|
| Degree of protection (IP) | IP66 |
| Impact strength | IK07 |
| Glow wire test | 850°C |
| Risk group (EN 62471) | RG1 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 0.5% |
| 230V Cable length | 1 m |
| Housing colour | Black |
|---|---|
| Optical material | Polycarbonate |
| Cover material | Tempered glass |
| Pressure valve | Yes |
| Coastal proof | Yes |
| Length | 286 mm |
|---|---|
| Width | 236 mm |
| Height/depth | 40 mm |
| Application temperature | 25°C |
|---|---|
| Storage environment | -40|60°C |
| Operating temperature | -30|50°C |
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 6941491737102 | 94054239 | CT | 1 | 0.301 x 0.045 x 0.312 m | 2.16 KG |
