Specifications
Electrical data
| Max. system power | 70 W |
|---|---|
| Nominal voltage | 220|240 V |
| Voltage type | AC/DC |
| Frequency | 50/60 Hz |
| Power factor | 0.9 |
Photometrical data
| Equivalent to | 2x TLM 140W RS |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 11200 lm |
| Luminaire efficacy | 160 lm/W |
| Colour rendering index CRI | ≥ 80 |
Light technical data
| Beam angle | 60° |
|---|
Lifespan
| Lifetime (L70) | 70000 |
|---|---|
| On-/Off-cycles | 100000 |
| Lifetime (L80) | 50000 h |
Capabilities
| Dimmability | DALI |
|---|
Certificates and standards
| Degree of protection (IP) | IP20 |
|---|---|
| Impact strength | IK02 |
| Protection class | I |
| Risk group (EN 62471) | RG0 |
| With control gear | Yes |
|---|---|
| Type of control gear | LED operating device current-controlled |
| Material housing | Steel |
|---|---|
| Colour housing | White |
| Reflector | None |
| Length | 1500 mm |
|---|---|
| Width | 70 mm |
| Height/depth | 40 mm |
| Weight | 2.11 kg |
| Application temperature | 25 °C |
|---|---|
| Operating temperature | -25|40 °C |
| Storage environment | -25|50 °C |
| EAN code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|
| 06941408874050 | Carton | 1 | 1498.5 x 77.7 x 66.5 mm | 2.11 kg |
