Specifications
Electrical data
| Max. system power | 9 W |
|---|---|
| Nominal voltage | 220|240 V |
| Voltage type | AC |
| Frequency | 50/60 Hz |
| Power factor | 0.9 |
| Max. inrush current | 5.92 A |
| Inrush time | 280 µs |
Photometrical data
| Equivalent to | TL 1x18W |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 900 lm |
| Luminaire efficacy | 100 |
| Colour rendering index CRI | ≥ 80 |
Light technical data
| Beam angle | 140 |
|---|
Lifespan
| Lifetime (L70) | 40000 |
|---|---|
| Lifetime (L80) | 30000 |
| On-/Off-cycles | 100000 |
Capabilities
| Dimmability | On-Off |
|---|
Certificates and standards
| Degree of protection (IP) | IP20 |
|---|---|
| Protection class | II |
| Risk group (EN 62471) | RG0 |
| With control gear | Yes |
|---|---|
| Type of control gear | LED operating device current-controlled |
| 230V Cable length | 1.5 m |
| Material housing | Polycarbonate (PC) |
|---|---|
| Colour housing | White |
| Length | 600 mm |
|---|---|
| Width | 21.8 mm |
| Height/depth | 34.6 mm |
| Weight | 0.143 kg |
| Application temperature | 25 °C |
|---|---|
| Operating temperature | -20|40 °C |
| Storage environment | -25|50 °C |
| EAN code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|
| 06956712666260 | Blister pack | 1 | 925 x 29 x 37 mm | 0.264 kg |
